WinBartlett

Multiplies a vector by a Bartlett windowing function.

Syntax

IppStatus ippsWinBartlett_16s(const Ipp16s* pSrc, Ipp16s* pDst, int len);

IppStatus ippsWinBartlett_32f(const Ipp32f* pSrc, Ipp32f* pDst, int len);

IppStatus ippsWinBartlett_64f(const Ipp64f* pSrc, Ipp64f* pDst, int len);

IppStatus ippsWinBartlett_16sc(const Ipp16sc* pSrc, Ipp16sc* pDst, int len);

IppStatus ippsWinBartlett_32fc(const Ipp32fc* pSrc, Ipp32fc* pDst, int len);

IppStatus ippsWinBartlett_64fc(const Ipp64fc* pSrc, Ipp64fc* pDst, int len);

IppStatus ippsWinBartlett_16s_I(Ipp16s* pSrcDst, int len);

IppStatus ippsWinBartlett_32f_I(Ipp32f* pSrcDst, int len);

IppStatus ippsWinBartlett_64f_I(Ipp64f* pSrcDst, int len);

IppStatus ippsWinBartlett_16sc_I(Ipp16sc* pSrcDst, int len);

IppStatus ippsWinBartlett_32fc_I(Ipp32fc* pSrcDst, int len);

IppStatus ippsWinBartlett_64fc_I(Ipp64fc* pSrcDst, int len);

Include Files

ipps.h

Domain Dependencies

Headers: ippcore.h, ippvm.h

Libraries: ippcore.lib, ippvm.lib

Parameters

pSrc	Pointer to the source vector.
pDst	Pointer to the destination vector.
pSrcDst	Pointer to the source and destination vector for the in-place operation.
len	Number of elements in the vector.

Description

This function multiplies the vector pSrc by the Bartlett (triangle) window, and stores the result in pDst.

The in-place flavors of ippsWinBartlett multiply the pSrcDst by the Bartlett (triangle) window and store the result in pSrcDst.

The complex types multiply both the real and imaginary parts of the vector by the same window.

The Bartlett window is defined as follows:

Return Values

ippStsNoErr	Indicates no error.
ippStsNullPtrErr	Indicates an error when the pSrc, pDst, orpSrcDst pointer is NULL.
ippStsSizeErr	Indicates an error when len is less than 3.

Example

The example below shows how to use the function ippsWinBartlett_32f_I.

void bartlett(void) {
      Ipp32f x[8];
      ippsSet_32f(1, x, 8);
      ippsWinBartlett_32f_I(x, 8);
      printf_32f(“bartlett (half) =”, x, 4, ippStsNoErr);
}

Output:

    bartlett (half) =  0.000000 0.285714 0.571429 0.857143
Matlab* Analog:
    >> b = bartlett(8); b(1:4)'
